- Place of Origin: Shandong, China
- Brand Name: Gongming
- Model Number: GM-1325
- Weight: 1700.000 kg
- :
- :
- :
- :
- :
- :
- :
- :
- :
- :
Product Description
1. With very high precision for cutting SS MS and other metals.
2. Any plasma source can work with the machine well.
3. Small cutting gap, with no residua
4. Light design of the beam promises
Applicable Industries & Materials:
CNC plasma engraving machine is an automatic and high efficiency engraving equipment. It is widely used in all kinds of carbon materials, stainless steel and nonferrous metal precision sheet metal cutting.
- Place of Origin: Shandong, China
- Brand Name: Gongming
- Model Number: GM-1325
- Weight: 1700.000 kg
- :
- :
- :
- :
- :
- :
- :
- :
- :
- :
Technical parameters :
Description | Parameter |
Model Number | GM-1325 |
Cutting Size | 1300mm*2500mm |
Size of table | 1500mm*2500mm |
Table Type | T-slot table |
Cross Beam Length(X axis) | 4m(can be lengthened according to user's demand) |
Longitudinal Rail Length(Y axis) | 6m (Rail can be lengthened according to user's demand) |
Effective Cutting Width (X axis) | 3.2m |
Effective Cutting Length (Y axis) | 4.8m |
Cutting Speed | 0-3500mm/min |
Cutting Mode | Flame only; Plasma only; Flame and Plasma |
Drive Mode | Dual-side |
Drive Method | Rack and pinion drive for X and Y axes |
Flame Cutting Thickness | 5-200mm |
Plasma Cutting Thickness | 1-60mm (according to the specification of plasma power source) |
Moving Precision | 0.01mm per step |
Power Source | 220V 50Hz 500-1000W |
Cutting Gas | Acetylene, Propane |
Plasma Gas | Pressed air, Oxygen, N2 |
Torch Height Controller (AUTO) | CHC600, Capacitive height control for flame cutting CHC330, Arc voltage height control for plasma cutting |
